DETAILED INFORMATION
We are a leading brass foils supplier in India, providing quality brass foils at competitive prices. Our Brass Metal Foils are highly durable, tensile strong, and resistant to adverse conditions. Additionally, Industrial Brass foils are available in various thicknesses and dimensions for diverse applications.
In India, we are a leading supplier of brass foils. Foils made from brass come in a variety of qualities. Hardness options are available in a variety of levels. Besides their superior tensile strength, excellent finish, and durability, these brass foil rolls are highly demanded.
Depending on the ratio of copper to zinc, brass can be formed. Brass Foils Roll Properties are determined by their proportion of alloyed elements. This alloy has the same crystal structure as brass, so Brass Foils Suppliers often call it a substitutional alloy. Brass strips are the most appropriate term.
Brass Foils Specification
|
Standard |
ASTM B36, ASME SB36 |
|
Brass Sheet, Plates Thickness |
0.001 mm – 70 mm |
|
Brass Plates Size |
14 X 48 inch, 16 X 48 inch |
|
Finish |
Hot rolled (HR), Cold rolled (CR), Galvanized, etc. |
|
Material |
Brass |
|
Grades |
UNS C21000, C22000, C22600, C23000, C24000, C26000, C26800, C27200, or C28000. |
Brass Foils Chemical Properties
|
Brass |
Cu |
Fe |
Pb |
Zn |
|
Min./Max. |
60.0-63.0 |
0.35 |
2.5-3.0 |
Rem. |
|
Nominal |
61.5 |
– |
2.7 |
35.4 |
Brass Foils Equivalent
|
Grade |
C21000 |
C22600 |
C23000 |
C24000 |
C26000 |
C26130 |
C26800 |
C27000 |
C27200 |
C27400 |
C28000 |
Brass Foils Physical Properties
|
Properties |
US Customary |
|
Melting Point -Liquidus |
1650 F |
|
Melting Point -Solidus |
1630 F |
|
Density |
0.307 lb/in3at 68 F |
|
Electrical Resistivity |
39.90 ohms – cmil/ft @ 68 F |
|
Electrical Conductivity |
26 %IACS @ 68 F |
|
Thermal Conductivity |
67 Btu · ft/(hr · ft2·oF)at 68F |
|
Modulas of Elasticity in Tension |
14000 ksi |
Brass Foils Size Range
|
Standard Size |
Thickness |
|
1000 × 2000 mm |
1.2 mm to 16 mm |
|
1250 × 1250 mm |
0.5mm to 25 mm |
|
1250 × 2500 mm |
1.2 mm to 12 mm |
|
2’x4’,16’’x48’’,14’’x48’’ |
0.3 mm to 25 mm |
Advantages of Brass Foils
Brass foils have several advantages, making them an excellent choice for various applications. Brass foils have the following benefits:
A warm golden color provides a visually appealing finish to brass products due to its attractive appearance. This product is often used in decorative applications where aesthetics are essential.
Brass is highly malleable, making it easy to shape and form into different shapes and configurations. Brass foil has this property, which allows it to create intricate designs and be used in jewelry making, embossing, and metal craft applications.
Brass’ corrosion resistance makes it ideal for environments where exposure to moisture or other corrosive elements is a concern, as the metal resists corrosion. Electrical connectors, gaskets, and outdoor components can all benefit from the properties of brass foils, which make them ideal for use in marine and outdoor settings.
The good electrical conductivity of brass makes it a good material for electrical and electronic applications. Electrical contacts, connectors, terminals, and circuit boards commonly use them as electrical contacts.
The excellent thermal conductivity of brass makes it a great material for transferring heat. As brass foils dissipate heat well, they are suitable for many applications, including heat sinks and cooling systems, where heat dissipation is critical.
Brass is malleable and durable, which means it can be stretched and bent without breaking. The ease of working with brass foils also makes it possible to form and shape them into complex shapes and designs.
Due to brass foil’s widespread availability, brass foils offer a cost-effective solution. Its versatility and cost-effectiveness make it an ideal choice for a wide range of applications.
Disadvantages of Brass Foils
Brass foils have several advantages, but they also have several potential disadvantages. The following are some of them:
Brass can develop a patina over time due to exposure to air, moisture, or certain chemicals. This tarnish can cause the brass foil to lose its original luster, which requires periodic cleaning and maintenance to maintain its appearance.
Brass is lessening and more durable than other metals due to its low strength and hardness. High stress or heavy loads may increase the susceptibility of brass foils to deformation or damage. Another metal or alloy may be more appropriate for applications requiring high mechanical strength.
The melting point and temperature resistance of brass are lower than those of some other metals. The material can lose its strength and become soft at high temperatures. The application may require alternative materials if it involves high temperatures or is subjected to extreme temperatures.
Dezincification potential: Brass is a copper and zinc alloy, and under certain conditions, such as acidic or alkaline environments, it may dezincify. By removing selective amounts of zinc from the brass alloy, it weakens, causing it to fail. Dezincification refers to this process. To mitigate this risk, it is necessary to consider the environment carefully and select appropriate alloys based on their characteristics.
Brass alloys have properties such as corrosion resistance and mechanical strength that can be affected by changing alloy composition. Ensure the brass foils used in the intended application meet the required specifications and standards.
Brass foil prices can fluctuate with market conditions, as other metals are also subject to market fluctuations. As a result, brass foils can be less cost-effective than other materials for specific applications.
Brass Foils Features
-
High corrosion resistance
-
Good durability
-
High electrical conductivity
-
High strength
Various Types Of Brass Foils
-
Grade 260 Brass Sheet
-
0.2mm perforated brass sheet
-
spring rigid brass sheet c2680 h65
-
2mm Polished Brass Hot Rolled Plate
-
Cutting Brass Sheet
-
Brushed Brass Sheet
-
Polished Brass Sheet
-
Brass Foil Sheet
-
Red Brass Sheet
-
Brass Shims
-
Brass Strips
-
Brass Foil Roll
Brass Foil Size
|
SIZE |
WEIGHT |
|
mm |
kg/sheet |
|
2000 x 1000 x 6.0 |
103.2 |
|
1800 x 900 x 3.0 |
41.49 |
|
1800 x 900 x 5.0 |
69.09 |
|
2000 X 600 X 3.0 |
30.72 |
|
2000 X 600 X 2.5 |
25.6 |
|
2000 x 600 x 2.0 |
20.52 |
|
2000 x 600 x 1.5 |
15.45 |
|
2000 X 600 X 1.2 |
12.2 |
|
2000 X 600 X 1.0 |
10.3 |
|
2000 X 600 X 0.8 |
8.19 |
|
2000 X 600 X 0.6 |
6.15 |
|
2000 X 600 X 0.5 |
5.14 |
|
2000 X 600 X 0.4 |
4.1 |
|
Engravers Brass sheet |
|
|
2000 X 600 X 6.0 |
61.49 |
|
2000 X 600 X 5.0 |
51.24 |
|
2000 X 600 X 3.0 |
30.8 |
|
2000 X 600 X 2.0 |
20.5 |
|
2000 X 600 X 1.5 |
15.45 |
|
2000 X 600 X 1.0 |
10.3 |
Brass Foil Roll Weight Chart In Mm
|
THICKNESS |
1.2M X 0.6M |
2M X 1M |
WEIGHT PER SQUARE METRE |
|
|
Imperial |
Metric |
Weight per sheet in Kg |
||
|
4″ |
101.6 |
|
1758 |
879 |
|
3″ |
76.2 |
|
1318 |
659 |
|
2.1/2″ |
63.5 |
|
1098 |
549 |
|
2″ |
50.8 |
|
880 |
440 |
|
1.1/2″ |
38.1 |
|
660 |
330 |
|
1.1/4″ |
31.75 |
203.88 |
550 |
275 |
|
1″ |
25.4 |
163.1 |
440 |
220 |
|
7/8″ |
22.22 |
143.03 |
384 |
192 |
|
3/4″ |
19.05 |
122.32 |
324 |
165 |
|
5/8″ |
15.88 |
102.1 |
275 |
137 |
|
1/2″ |
12.7 |
81.69 |
220 |
110 |
|
3/8″ |
9.53 |
61.26 |
165 |
83 |
|
5/16″ |
7.94 |
51.07 |
137.36 |
69 |
|
1/4″ |
6.35 |
40.84 |
110 |
55 |
|
3/16″ |
4.77 |
30.61 |
82.4 |
41 |
|
Ten swg |
3.251 |
20.9 |
56.225 |
28 |
|
12 swg |
2.642 |
16.98 |
46 |
23 |
|
13 swg |
2.337 |
15.05 |
40.43 |
20 |
|
14 swg |
2.032 |
13.05 |
35.2 |
17.6 |
|
16 swg |
1.626 |
10.46 |
28.13 |
14 |
|
18 swg |
1.218 |
7.85 |
21.07 |
10.5 |
|
20 swg |
0.914 |
5.88 |
15.81 |
7.7 |
|
21 swg |
0.813 |
5.23 |
14.06 |
7.03 |
|
22 swg |
0.711 |
4.57 |
12.3 |
6.15 |
|
24 swg |
0.559 |
3.6 |
9.66 |
4.83 |
|
26 swg |
0.457 |
|
7.9 |
3.95 |
|
28 swg |
0.376 |
|
6.5 |
3.25 |
|
30 swg |
0.315 |
|
5.44 |
2.7 |
Dimension Of 360 Brass Foils
|
Plate Surface finish |
Thickness (mm) |
Width (max mm) |
|
2B – Cold rolled, heat treated, pickled, skin passed Sheet |
0.25–8.0 |
2032 |
|
2D – Cold rolled, heat treated, pickled Sheet |
0.4–6.35 |
1524 |
|
2E – Cold rolled, heat treated, mechanically descaled plate |
0.4–8.0 |
2032 |
|
2R – Cold rolled, bright annealed plate |
0.25–3.5 |
1524 |
|
2H – Work-hardened plate |
0.4–6.35 |
1524 |
|
Polished, brushed plate |
0.5–4.0 |
1524 |
360 Brass Shims Imperial Dimensions
|
Plate Surface finish |
Gauge (in) |
Width (max in) |
|
2B – Cold rolled, heat treated, pickled, skin passed Plate |
10–24 |
72* |
|
2D – Cold rolled, heat treated, pickled plate |
12–24 |
60 |
|
BA Mexinox only |
18–28 |
48 |
|
Polished Sheet (not brushed) |
11–24 |
60 |
|
Temper rolled Sheet Mexinox only |
13–29 |
48 |
Brass Foils Thickness Chart
|
PRODUCT |
FINISH |
THICKNESS MM |
MAX SHEET SIZE MM |
|
Natural |
Semi Bright |
0.3*, 0.4*, 0.5, 0.7, 0.9, 1.2, 1.5, 2.0, 3.0 |
2000 x 1000, *(1200 x 600) |
|
Mirror |
Bright Polished |
0.5, 0.9, (other thickness’ to order) |
2000 x 1000 |
|
Brushed |
Dull Polish |
(all thicknesses to order) |
2000 x 1000 |
|
Bronzed |
Antique |
(all thicknesses to order) |
2000 x 1000 |
Brass Foil Size
|
SIZE |
WEIGHT |
|
mm |
kg/sheet |
|
2000 x 1000 x 6.0 |
103.2 |
|
1800 x 900 x 3.0 |
41.49 |
|
1800 x 900 x 5.0 |
69.09 |
|
2000 X 600 X 3.0 |
30.72 |
|
2000 X 600 X 2.5 |
25.6 |
|
2000 x 600 x 2.0 |
20.52 |
|
2000 x 600 x 1.5 |
15.45 |
|
2000 X 600 X 1.2 |
12.2 |
|
2000 X 600 X 1.0 |
10.3 |
|
2000 X 600 X 0.8 |
8.19 |
|
2000 X 600 X 0.6 |
6.15 |
|
2000 X 600 X 0.5 |
5.14 |
|
2000 X 600 X 0.4 |
4.1 |
|
Engravers Brass sheet |
|
|
2000 X 600 X 6.0 |
61.49 |
|
2000 X 600 X 5.0 |
51.24 |
|
2000 X 600 X 3.0 |
30.8 |
|
2000 X 600 X 2.0 |
20.5 |
|
2000 X 600 X 1.5 |
15.45 |
|
2000 X 600 X 1.0 |
10.3 |
Brass Foil Application
-
Plumbing
-
Heating
-
Water Supply Systems
-
Paper & Pulp Industry
-
General Purpose Applications
-
Fabrication Industry
