•  Tisco Stainless Steel 304 foil
• SS 304 Perforated foil
• Stainless Steel 304 UNS S30400 foil
• A 240 Chequered 304 foil
• Aperam Stainless Steel 304 foil
• Grade 304 Industrial Foil
• Stainless Steel 304 foil
• A 240 304 foil
• SS 304 Embossed foil
• Outokumpu SS 304 foil
• SA 240 304 Stainless Steel foil
• Bright Hammered Pattern Decorative SS 304 foil
• Jindal Stainless Steel 304 foil
• SS DIN 1.4301 foil
• ThyssenKrupp Stainless Steel 304 foil
• ASTM A240 Stainless Steel 304 foil
• Surface Polishing SS 304 foil
• 304 Stainless Steel HR foil
• 304 Stainless Steel Chequered foil
• 304 Stainless Steel Golden Laser Pattern foil
• Super thin-Mirror surface BA ss 304 foil
• Super Austenitic SS 304 foil
• ASTM A240 304 foil
• JMSS cold rolled ss 304 foil
• Cold Rolled No.1 Finish SS 304 foil
• SEW 400 Stainless Steel 304 foil
• Hot Rolled Stainless Steel 304 foil
• Sales Promotion SS 304 foil
• Cr Stainless Steel 304 foil
• SS 304 Mill Test Certificate foil
• ASTM A240 304 foil
• Cold rolled, bright annealed 304 foil
• Ground Stainless Steel 304 foil
• Hot Selling AISI SS 304 foil
• SS 304 Rose Golden foil
• Surface-coated Stainless Steel 304 foil
• Satin finish Stainless Steel 304 foil
• AISI stainless steel 304 armor foil
• Satin finish Stainless Steel 304 foil
• Mirror Finish SS 304 foil
• SS 304 foil Gold Brush Finish
• 304 Stainless Steel CR foil
• 304 Stainless Steel 2B foil
• 304 Stainless Steel B. Q. Profile foil
• Best selling 4’x8′ mirror finished ss 304 foil
• Decorative hairline inox cold rolled ss 304 foil
• Hair Line Finish SS 304 foil
• Laser cutting ss 304 foil
• Tisco Supplier 3mm Thickness Stainless Steel 304 foil
• Decorative Stainless Steel 304 foil
• Scotch Brite SS 304 foil
• Baosteel Stainless Steel 304 foil
• Stainless Steel Cladding 304 foil
• Black SS 304 foil 4mm Thick
• Bright-pickled Stainless Steel 304 foil
• Cold rolled, heat treated 304 foil
• 3mm Cold Rolled AISI SS 304 foil
• Mill Supply SS 304 foil
• Grade Prime SS 304 foil
• Carpenter Custom 450 Stainless Steel 304 foil
• Cut to Size Stainless Steel 304 foil
• Non Magnetic Polishing Stainless Steel 304 foil
• ASME SA240 304 foil
• 304 Stainless Steel Blank foil
• 304 Stainless Steel Perforated foil
• Embossed ss 304 foil
• Cheap cold rolled ss 304 foil with the best price
• Brush finish ss 304 foil price list
• SS URANUS B6 304 foil
• 2B SUS SS 304 foil
• Food Grade Stainless Steel 304 foil
• No. 4 PVC Coated SS 304 foil
• SS 304 foil Blasted Tin-Gold Rose
• 2mm ASTM SS 304 foil
• Stainless Steel Corrugated 304 foil
• ASTM B625 304 foil
• Brushed or dull polished Stainless Steel 304 foil
• Cold rolled, heat treated, pickled 304 foil
• 10K Mirror Finish Surface SS 304 foil
• Gold Etched SS 304 foil
• 18 Gauge SS 304 foil
• Patterned Stainless Steel 304 foil
• #4 Finish Stainless Steel 304 foil
• Patterned Stainless Steel 304 foil
• Passenger Elevator Cabin SS 304 foil

• Positive Material Identification – PMI Testing
• Chemical Analysis – Spectro Analysis
• Mechanical Testing Such as Tensile, Elongation, Reduction of Area
• Micro Test
• Macro Test
• Hardness Test
• Pitting Resistance Test
• Intergranular Corrosion (IGC) Test
• Flaring Test
• Flattening Test
• Hydrostatic Test
• Hydrogen-Induced Cracking (HIC) Test, NACE TM0284
• Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177
• Radiography Test
• Dye Penetrant Test (DP Test)
• Ultra Sonic Test (UT)
• Eddy Current Testing
• Impact Test
• Bend Test

As one of the best corrosion-resistant steels available, 304 can withstand a wide range of environments and can be used with various corrosive media. Pitting and crevice corrosion can occur in chloride-containing environments. Stress corrosion cracking can occur at temperatures over 60°C.

In intermittent service up to 870°C and continuous service up to 925°C, 304 has good oxidation resistance. Despite this, continuous use of 304L is not recommended at temperatures of 425- 860°C due to its resistance to carbide precipitation. When high strength is required at temperatures above 500°C, grade 304H should be chosen. This grade will retain aqueous corrosion resistance at temperatures above 500°C and up to 800°C.

It is essential to use stainless steel-specific tools for fabrication. Before using stainless steel, tooling, and work surfaces should be thoroughly cleaned. These precautions are necessary to prevent cross-contamination of stainless steel by easily corroded metals that may discolor the fabricated product’s surface.

In the case of cold working methods, 304 stainless steel is readily susceptible to work hardening, so an intermediate annealing stage may be necessary to alleviate work hardening and prevent tearing or cracking. Employing a full annealing operation after fabrication is important to reduce internal stresses and improve corrosion resistance.

To ensure maximum corrosion resistance, fabrication methods such as forging that involve hot working should be carried out after uniform heating to 1149-1260 degrees Celsius. The fabricated components should then be rapidly cooled to ensure maximum corrosion resistance.

A good way to improve machining 304 is to keep the cutting edges sharp. Dull edges lead to excessive hardening of the material. To prevent work hardening by riding on the material’s surface, cuts should be made that are light and deep enough to prevent it from riding. A chip breaker is an excellent tool to help prevent swarf from getting into the work area, as austenitic alloys have a low thermal conductivity, which causes heat to concentrate at the cutting edges. As a result, coolants and lubricants must be used in large quantities and be of high quality.

Heat treatment cannot be used to harden 304 stainless steel. A solution treatment or annealing can be done by rapid cooling after the steel has been heated to 1010-1120 degrees Celsius.

The fusion welding performance of stainless steel 304 is excellent. The best fillers and electrodes for stainless steel 304 are grade 308, while the recommended filler rods and electrodes for 304L are grade 308L. Heavy welded sections may require post-weld annealing. If post-weld heat treatment is not feasible, grade 321 may be used.

1. Raw Materials Preparation

To ensure the quality of the goods, the origin manufacturer issues a product quality certificate for every batch of goods.

In addition, our company will conduct a thorough inspection of the raw materials sent to the factory, and we will select raw materials to be sampled and used for spectral analysis.

This type of testing can detect the ingredients present in the raw materials. We will compare and confirm that the ingredients are accurate in the raw materials. We will check with the manufacturer’s quality certificate.

Quality control involves checking details such as thickness tolerance, coil width, outside packaging, label marks, inside surface finish, chemical components, etc.

Furthermore, we will save some raw materials and finished products of precision 304 stainless steel foils. We will send them to qualified testing institutions regularly so that the testing institutions will be able to test our precision stainless steel foils and raw materials using professional instruments.

As part of our quality control system, we ensure that all standards of the national technical specifications are met with our products.

2. Cold Rolling

In this step of the manufacturing process of precision thin 304 stainless steel foils, a cold rolling mill is used to achieve the desired thickness of the foil, a machine that also ensures a good surface finish, the flatness of the strip, and a variation in thickness that meets international standards.

It is important to mention that the twenty-high rolling mill equipment is also important to mention. The twenty-high rolling mill consists of the stand, roll system, roll box, pressing device, and driving device.

With the rectangular saddle and the housing, stainless steel foil can be produced with a thickness of up to 0.001mm. The matching accuracy is high, and the lower roll box allows the line to maintain a standard height.

With cold rolling, we can achieve super thin 304 stainless steel foils with a thickness of 0.02mm.

3. Bright Annealing

During this step, the whole surface of the 304 stainless steel foil body is subjected to the metallurgical process.

As a result of the heat treatment, the microstructure of the foil material is altered to provide the desired mechanical properties while it is in use as a result of the treatment.

A thin 304 stainless steel foil is processed for bright annealing treatment in a continuous annealing line, where the foil can be cooled rapidly under bright annealing conditions.

It is estimated that the thin stainless steel foil travels at a speed of 60-80 meters per minute on the line.

4. Degreasing

It is necessary to clean the residual oil left on the surface of the thin 304 stainless steel foils due to the stains created during the rolling process.

A chemical reaction (saponification reaction) is used between an alkaline agent and grease on the surface to remove grease from steel foils.

Three hundred four stainless steel foils of 0.02mm-1.0mm thickness. This unit can handle 304 stainless steel foils of 0.02mm-1.0mm thickness at 60 meters per minute.

5. Tension Straightening Process

It is difficult to deform thin 304 stainless steel foil rolled on a twenty-high rolling mill with a thickness of 0.02mm-0.8mm.

With complete softening and large tension leveling, stretch bending straightening is the only way to eliminate the stress of steel stainless foil in the condition of complete softening and large tension leveling.

As part of the tension leveling, the steel foil is subjected to a skin pass mill, a machine that, in addition to improving the mechanical properties, also helps to improve the final brightness of the steel foil. By doing this, we guarantee all the desired characteristics of the final foil product.

When the stainless steel foil is straightened, the stress distribution in the entire foil is more uniform, and the plate shape is straight due to straightening the stainless steel foil.

By applying excellent control and management to the production process, we can assure the straightness of each stainless steel foil in various hardness and temper levels.

6. Slitting Process

As a part of the super thin 304 stainless steel foils slitting process, our staff will use a precision and small machine to cut the narrow thin coils of foils. The thickness of the thin roll foils lies in the range of 0.02mm to 0.08mm.

When our workers are preparing to slit a finished coil, they will make adjustments between the coils and tools to minimize the burr on the edge of the strip as much as possible when preparing to slit.

In the manufacture of cold rolled precision thin stainless steel foils made from 304 stainless steel, the manufacturing process ends with the slitting of the cold rolled sheets of precision steel foil, where slitting knives of the highest precision are used to achieve the final width and burr level of the cold rolled precision thin stainless steel sheets.

When ordering from infinixsteelalloy.com, we ensure that the packaging is of the best quality, as it plays a crucial role, especially in the case of international shipments, where the consignment passes through various channels before arriving at its ultimate destination, so we place an exceptional amount of emphasis on the packaging.

Depending on the product we are shipping, we pack our goods differently. Some of the ways we pack our products include:

• Boxes and Crates
• Shrink-wrapped
• Carton boxes
• Wooden pallets
• Wooden boxes
• Wooden crates

• 304 Stainless Steel foil Used in Tractor
•   304 Stainless Steel foil Used in Automotive Trim
•   304 Stainless Steel foil Used in Stamped Machined Products
•   304 Stainless Steel foil Used in Cookware
•   304 Stainless Steel foil Used in Appliances
•   304 Stainless Steel foil Used in Kitchen
•   304 Stainless Steel foil Used in Foodservice Equipment
•   304 Stainless Steel foil Used in Sinks
•   304 Stainless Steel foil Used in Railway Cars
•   304 Stainless Steel foil Used in Trailers
