DETAILED INFORMATION
As a supplier and exporter of high-quality stainless steel shims, Pearlshims.com is well known in the industry. Furthermore, several other characteristics make SS Shims a highly sought-after product, including its approved quality, compact design, corrosion resistance, durability, ease of maintenance, and durability. Apart from being highly durable, it also has some other desirable properties, such as high tensile strength, ductility, toughness to heavy loads, and noncorrosive design. Shims made of perforated SS Shims are highly resistant to oxidation under intermittent service up to 870 degrees Celsius, and under continuous service up to 925 degrees Celsius. It is one of the highest quality SS shims available and is suitable for many corrosive media and atmospheric conditions. As well as that, it is capable of withstanding up to about 200 mg/L of chloride in water at room temperature.
SS Shims is commonly used for brewing, processing milk and wine, building kitchen benches, sinks, troughs, equipment, and appliances, as well as architectural panels, railings, and trim, as well as chemical containers like heat exchangers for transport, woven or welded screens for mining, quarrying, and water filtering, and threaded fasteners.
This austenitic stainless steel contains 18% chromium and 8% nickel and is one of the most popular austenitic stainless steels. As a result, it is widely used and comes in a variety of sizes, types, and specifications. In addition to excellent corrosion resistance, SS Shims also provide superior surface finish, high strength, and high heat resistance.
SS Shim Specifications:
| Grades | SS Shims J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L |
| Thickness | 0.02mm – 5.0mm |
| Width | 3.2mm – 1500mm |
| Length | AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | SS SHIMS SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Make | JINDAL, BAHRU, POSCO KOREA, POSCO THAINOX, COLUMBUS, ACERINOX, APERAM, TISCO, NISSHIN, NIPPON AND MANY MORE MILLS. |
Chemical Composition Of SS Shim
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|
304 |
min. max. |
– 0.08 |
– 2.0 |
– 0.75 |
– 0.045 |
– 0.030 |
18.0 20.0 |
– |
8.0 10.5 |
– 0.10 |
Astm A240 SS Shim Mechanical Properties
|
Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness |
|
|
Rockwell B (HR B) max |
Brinell (HB) max |
||||
|
304 |
515 |
205 |
40 |
92 |
201 |
Equivalent Grades Of SS Shim
|
Grade |
UNS No |
Old British |
Euronorm |
Swedish SS |
Japanese JIS |
AFNOR |
GOST |
||
|
BS |
En |
No |
Name |
||||||
|
304 |
S30400 |
304S31 |
58E |
1.4301 |
X5CrNi18-10 |
2332 |
SUS 304 |
Z7CN18-09 |
08Х18Н10 |
SS Shim Physical Properties
|
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion (μm/m/°C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Electrical Resistivity (nΩ.m) |
|||
|
0-100°C |
0-315°C |
0-538°C |
at 100°C |
at 500°C |
|||||
|
304 |
8000 |
193 |
17.2 |
17.8 |
18.4 |
16.2 |
21.5 |
500 |
720 |
SS Shim Stock Available
- Tisco Stainless Steel shim
- SS Perforated shim
- stainless steel shim
- A 240 Chequered shim
- Aperam Stainless Steel shim
- Stainless Steel shim
- A 240 shim
- SS Embossed shim
- Outokumpu SS shim
- SA 240 Stainless Steel shim
- Bright Hammered Pattern Decorative SS shim
- Jindal Stainless Steel shim
- SS DIN 1.4571 shim
- ThyssenKrupp Stainless Steel shim
- ASTM A240 Stainless Steel shim
- Surface Polishing SS shim
- Stainless Steel HR shim
- Stainless Steel Chequered shim
- Stainless Steel Golden Laser Pattern shim
- Super thin-Mirror surface BA ss shim
- Super Austenitic SS shim
- ASTM A240 shim
- JMSS cold rolled ss shim
- Cold Rolled No.1 Finish SS shim
- SEW 400 Stainless Steel shim
- Hot Rolled Stainless Steel shim
- Sales Promotion SS shim
- Cr Stainless Steel shim
- SS 304 Mill Test Certificate shim
- ASTM A240 shim
- Cold rolled, bright annealed shim
- Ground Stainless Steel shim
- Hot Selling AISI SS shim
- SS Rose Golden shim
- Surface coated Stainless Steel shim
- Satin finish Stainless Steel shim
- AISI stainless steel armor shim
- Satin finish Stainless Steel shim
- Mirror Finish SS shim
- SS shim Gold Brush Finish
- Stainless Steel CR shim
- Stainless Steel 2B shim
- Stainless Steel B. Q. Profile shim
- Best selling 4’x8′ mirror finished ss shim
- Decorative hairline inox cold rolled ss shim
- Hair Line Finish SS shim
- Laser cutting ss shim
- Tisco Supplier 3mm Thickness Stainless Steel shim
- Decorative Stainless Steel shim
- Scotch Brite SS shim
- Baosteel Stainless Steel shim
- Stainless Steel Cladding shim
- Black SS shim 4mm Thick
- Bright-pickled Stainless Steel shim
- Cold rolled, heat treated shim
- 3mm Cold Rolled AISI SS shim
- Mill Supply SS shim
- Grade Prime SS shim
- Carpenter Custom 450 Stainless Steel shim
- Cut to Size Stainless Steel shim
- Non Magnetic Polishing Stainless Steel shim
- ASME SA240 shim
- Stainless Steel Blank shim
- Stainless Steel Perforated shim
- Embossed ss shim
- Cheap cold rolled ss shim with best price
- Brush finish ss shim price list
- SS URANUS B6 shim
- 2B SUS SS shim
Processing of SS shim
A majority of normal processing can be performed on SS Shims Pearlshims.com offers the following services for SS Shims:
- Testing of stainless steel shims
- Cutting SS Shims
- Grinding SS Shims
- SS Shims Forming Drilling/Making
Testing (destructive and non-destructive):
- Testing for Positive Material Identification (PMI)
- Spectroscopic Analysis of Chemicals
- Testing such as tensile, elongation, and reduction of area
- Testing on a micro scale
- Test of macros
- Test of hardness
- Test for Pitting Resistance
- Test for intergranular corrosion (IGC)
- Test for flare-ups
- Test for flattening
- Test of hydrostatic pressure
- A hydrogen-induced cracking test (HIC), NACE TM0284
- NACE TM 0177, Sulfide Stress Corrosion Cracking
- Test of radiography
- Test for dye penetration (DP test)
- Testing with ultrasonic waves (UT)
- Testing with Eddy Currents
- Test of Impact
- Test for bends
Application of SS Shim
- Tractor SS Shims
- Automotive SS Shims
- Stamped Machined Products Using SS Shims
- Cookware SS Shims
- Appliance SS Shims
- Kitchen SS Shims
- In foodservice equipment, SS shims are used
- Sink SS Shims
- In railway cars, SS shims are used
- Trailer SS Shims
The packaging:
Pearlshims.com ensures the best quality of packing, because it plays an important role, especially when it comes to international shipments. A shipment passes through various channels before it reaches its final destination, and we place great importance on packaging.
- Crates and boxes
- Wrapped in shrink
- Boxes for cartons
- Pallets made of wood
- Boxes made of wood
- Crates made of wood
